A closer look at the high-modulus carbon technology of the front wings in our Team Series and Pro Team Series ranges.

The Carbon technology in our Team Series and Pro Team Series integrates premium high-modulus Prepreg carbon fibers with a hydrophobic foam core for a structure that is both rigid, dynamic, and durable.

The carbon fiber is crucial for dynamism, offering maximum return speed.

Technical design:

3D shape designed with modeling software.
Hydrodynamic simulation and digital optimization.
Digital simulation of mechanical resistance.
CAD integration accounting for manufacturing constraints.
Mechanical testing on a test rig.
3D digital control.
Aging tests in real conditions.
Tests and validations by our Pro Team.

Production:

5-axis CNC machining of steel molds: precise and non-deformable.
5-axis CNC machining of an additional mold for manufacturing high-density foams.
Foam core production.
CNC cutting of layers and reinforcements.
Assembling the multiple layers and reinforcements onto the Foam Core.
Vacuum compression to remove air.
Thermal molding: a heating process at 150°C and uniform compression at 20 tons with the use of indestructible steel molds for increased durability and peak performance.
Progressive cooling.
CNC trimming.
Ultra-precise finishing.

Wingfoiler: Bastien, GONG team rider, with a Droid Boom, Stunt FSP Pro, HM85 mast and Ypra Surf-Freestyle V3 setup.

Structure and materials:

Fibers oriented in various directions (UD, biaxial, etc.) to control bending and twisting, while managing fatigue.
Prepreg fibers for perfect control of the fiber/resin ratio.
High-density hydrophobic foam core, highly resistant, forming a solid base for lamination. This foam is produced in a specific mold to ensure perfect control over compressions and shapes.

Specific reinforcements:

Sensitive zones reinforced with specific fibers to enhance rigidity and increase durability.
Sandwich connections in the areas where the wings and fuselage connect, ensuring maximum strength and cohesion.

Key benefits of the components:

High-density foam: waterproof, durable, and stable.
Prepreg Epoxy resin: perfectly balanced, durable, lightweight, and shock-resistant.
Carbon fibers: ultimate dynamism and resistance.
UD carbon fibers: offering absolute rigidity.
Biaxial carbon fibers: ensuring strength and torsion control.
12K fibers: for cohesion and finishing.

Foils with Carbon technology are tested and approved by our riders worldwide. Repairable and durable, they guarantee optimal performance in every program.
