Preshape by numerical control for total reliability.
Shape control by traditional templates, finishing off the last mm 100% by hand.
Epoxy resin and EPS foam blank: solid and lightweight.
Epoxy / fiberglass lamination on polystyrene foam blank 28kg / m³ with 3 stringers (central wood stringer and 2 lateral 3mm).
Deck detail: 2 layers of 6oz fiberglass
Hull detail: 1 layer of 6oz fiberglass, with 5 6oz fiberglass reinforcement patches and 1 6oz carbon patch around the
US rails to avoid breakage in front of the foil attachment during stalls.
PVC reinforcement 70kg / m3 with a thickness of 3.5 cm integrating the 2 US rails.
Resin tinted hot coat : nobility of the process, weight saving and solidity of the finish.
Hand-made matt “custom finish” for weight saving and a better glide.
This technology is easily repairable as new in the event of dings or accidents, and has an excellent lightness / nervousness ratio highlighting all the technical qualities of the shape.
It is THE modern technology currently popular with the most technical foilers looking for lightness and responsiveness.
These boards are 100% shaped and glassed in China in the most experienced factory in the manufacture of surfboards.
EPS PRO Technology
3D shape on modeling software.
Preshape by numerical control for total reliability.
Shape control by traditional templates, finishing off the last mm 100% by hand.
Epoxy resin and EPS foam blank: solid and lightweight.
Epoxy/carbon fiber and fiberglass stratification on a high density polystyrene blank 28kg/m³ reinforced by 3 wooden stringers of 3mm.
Deck detail: 1 layer of 6oz fiberglass and 1 layer of 6oz carbon fiber.
Hull detail: 1 layer of 6oz carbon fiber, with 2 patches of 6oz carbon fiber for reinforcement around the US rails to avoid breakage in front of the foil attachment during stalls.
PVC reinforcement 80kg/m3 with a thickness of 3.5 cm integrating the 2 US rails.
Resin tinted hot coat : nobility of the process, weight saving and solidity of the finish.
Hand-made matt “custom finish” for weight saving and a better glide.
This technology is easily repairable as new in the event of dings or accidents, and has an excellent lightness / dynamism ratio highlighting all the technical qualities of the shape.
These boards are 100% shaped and glassed in our factory in Asia, which strictly replicates our methods developed in France and tested worldwide.
FSP PRO Technology
Epoxy resin and EPS foam blank: solid and lightweight.
Vacuum-packed PVD sandwich deck, hull and rails: unrivalled strength and incredible dynamism.
Deck: full PVC/fiberglass/ carbon sandwich made up of a core of high-density PVC foram and 1 layer of 4oz fiberglass and 1 layer of 6oz carbon fiber, with fiberglass reinforcements in sensitive areas.
Hull: full PVC/fiberglass/ carbon sandwich with high-density PVC foam core and 1 layer of 6oz carbon fiber, fiberglass reinforcements in fragile areas.
Specific foil reinforcements: high-density PVC block for the two US rails. Three layers of carbon cover these boxes. Laminated PVC battens connect the reinforcement to the deck for maximum durability.
Rails: the PVC sandwich layer integrally covers the rails for increased structural solidity and very strong impact resistance.
Resin tinted hot coat : nobility of the process, weight saving and solidity of the finish.
Hand-made matt “custom finish” for weight saving and a better glide.
ICS Technology - Pros
Inflatable Carbon Synthesis
The advantages of inflatable technology
Woven Dropstitch double-layer welded technology with double layer rails.
Recommended pressure: 15 psi.
Transportation: it fits into a bag.
Practicality: it inflates in 2 minutes.
Safety: the dropstitch absorbs shocks.
Aesthetic: the appearance is very pleasing.
Durability: highly resistant to rough handling.
Longevity: 100% repairable.
The performances of prepreg carbon and fiberglass
ICS Full composite prepreg plate, top of the line.
High-density foam stringers to limit flex and weight.
US rails machined directly into the carbon: incredible performance.
Unrivaled stiffness on the market.
Unparalleled dynamism and responsiveness.
A foil + inflatable combination without any loss of sensation.
An durable board
PVC reinforcement under the plate to preserve the board with an additional layer.
PVC reinforcement on the plate to protect the carbon and adhesive from heat, and distribute the efforts as far as possible on the plate to avoid detachment.
Double non-through brass inserts connected by a carbon fiber rod to easily screw the foil without risking piercing the board.
The large diameter leash ring is the strongest on the market. This is essential for wingfoil use.
